神钢零件查询(MD180LC) - EXCAVATOR ASN YG0647 (1/80-12/06) (11-001) - VALVE ASSY, RELIEF Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
121 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436R679F1 | [1] | VALVE PRESSURE RELIE | KOBCONSISTS OF THE FOLLOWING PARTS |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONSOCKET |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONSEAT, VALVE |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONVALVE |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONPISTON |
| 5. | NSS | [1] | NOT SOLD SEPARAT | CONSHIM |
| 6. | NSS | [1] | NOT SOLD SEPARAT | CONSPRING |
| 7. | NSS | [1] | NOT SOLD SEPARAT | CONPLUG |
| 8. | 2483U156S14 | [1] | O-RING | KOB |
| 9. | ZD12G02500 | [1] | O-RING,24.40mm ID x 30.60mm OD x 3.10mm | KOBID 24.4 ± 0.25 x OD 30mm |
| 10. | ZD85G02500 | [1] | BACK-UP RING | KOBRing, Back-Up -- ID 25 x OD 30 x Th 1.25mm |
| . . | 2436R679R100 | [1] | HYDRAULIC VALVE | KOBCONSISTS OF REF 1-7 |
