纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-017[03]) - VALVE INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
949 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CONHousing |
| 2. | YT30V00039S002 | [1] | COVER | KOB |
| 3. | YT30V00039S004 | [8] | COVER | KOB |
| 4. | YT30V00039S041 | [1] | PLUG | KOB |
| 5. | YT30V00039S042 | [2] | FILTER | KOB |
| 6. | YT30V00039S043 | [2] | GUIDE | KOBCover |
| 7. | ZS28C06020 | [32] | SCREW,Hex Socket Head, M6 x 20mm | KOBCap |
| 8. | PY30V00001S026 | [16] | O-RING | KOB |
| 9. | ZD12P00800 | [15] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOB |
| 10. | 2436U1309S29 | [11] | CAP | KOB |
| 11. | ZD12P01100 | [24] | O-RING | KOB |
| 12. | 2436U1309S41 | [9] | CAP | KOB |
| 13. | YT30V00047S097 | [8] | COVER | KOB |
