纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-017[04]) - VALVE INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
1000 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YT30V00051F1 | [1] | VALVE | KOBControl, Flow |
| 2. | ZD12P02200 | [1] | O-RING | KOB |
| 3. | ZD12P02000 | [1] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOB |
| 4. | ZD85P02000 | [1] | RING | KOBBack-Up |
| 5. | ZD85P01800 | [1] | RING | KOBBack-Up |
| 6. | ZD12P01800 | [1] | O-RING | KOB |
| 7. | YT30V00039S023 | [8] | CAP | KOB |
| 8. | YT30V00039S024 | [18] | O-RING | KOB |
| 9. | 2436U2716S20 | [8] | SPRING | KOB |
| 10. | YT30V00039S026 | [8] | CHECK CONTROL | KOBPoppet |
| 11. | YT30V00039S033 | [8] | CAP | KOB |
| 12. | YT30V00039S035 | [5] | SPOOL | KOB |
| 13. | YT30V00039S037 | [3] | SPRING | KOB |
| 14. | YT30V00039S038 | [1] | PLUG | KOBAssy. |
| 15. | YT30V00039S039 | [2] | PLUG | KOBAssy. |
| 16. | YT30V00039S048 | [1] | PLUG | KOB |
| 17. | ZD12P00800 | [15] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOB |
| 19. | ZD12P01400 | [1] | O-RING | KOB |
| 20. | YT30V00042S022 | [6] | CAP | KOB |
| 21. | 2436U1309S29 | [11] | CAP | KOB |
| 22. | 2437U283S42 | [1] | PLUG | KOB |
| 23. | ZD12P02290 | [1] | O-RING | KOB |
| 25. | ZD12P01100 | [24] | O-RING | KOB |
| 28. | 2436U1309S41 | [9] | CAP | KOB |
| 29. | YT30V00039S089 | [5] | PLUG | KOB |
| 30. | YT30V00039S090 | [1] | CHECK CONTROL | KOB |
| 31. | YT30V00039S094 | [1] | SPRING | KOB |
| 32. | YT30V00039S095 | [2] | SPACER | KOB |
