神钢零件查询(MD180LC) - EXCAVATOR ASN YG0647 (1/80-12/06) (11-005) - VALVE ASSY, RELIEF Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
886 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436R686F1 | [1] | VALVE | KOBCONSISTS OF THE FOLLOWING PARTS |
| 101. | NSS | [1] | NOT SOLD SEPARAT | CONBODY |
| 201. | 2436R686S201 | [1] | PLUG | |
| 261. | ZD12G02500 | [1] | O-RING,24.40mm ID x 30.60mm OD x 3.10mm | KOBID 24.4 ± 0.25 x OD 30mm |
| 262. | 2436U749S563 | [1] | BACK-UP RING | KOB Superseded by part number: ZD85G02500 |
| 291. | 24036R83S291 | [1] | LOCKING RING | KOB |
| 301. | NSS | [1] | NOT SOLD SEPARAT | CONPLUNGER |
| 302. | NSS | [1] | NOT SOLD SEPARAT | CONPISTON |
| 303. | NSS | [1] | NOT SOLD SEPARAT | CONPISTON |
| 311. | 2436U625S232 | [1] | BALL | KOB |
| 321. | 2436R686S321 | [1] | SPRING | |
| 322. | 2436R686S322 | [1] | SPRING | |
| 323. | 24036R83S323 | [1] | SPRING | SPRING |
| 331. | 2436R686S331 | [1] | SEAT, SPRING | |
| 341. | NSS | [1] | NOT SOLD SEPARAT | CONSEAT |
| 342. | 2436R686S342 | [1] | BUSHING | KOB |
| 343. | 24036R83S343 | [1] | GUIDE, SPRING | GUIDE, SPRING |
| 361. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 362. | 2436R686S362 | [1] | BACK-UP RING | KOB Superseded by part number: ZD85P01400 |
| 471. | 24036R83S471 | [1] | BOLT, ADJUST | |
| 473. | 2436R683S671 | [1] | NUT | KOB Superseded by part number: ZN18C12007 |
| 851. | 2436R686S851 | [1] | CAP | KOB |
