纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-017[09]) - VALVE INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
757 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CONHousing |
| 2. | PY30V00001S026 | [2] | O-RING | KOB |
| 3. | YT30V00039S003 | [1] | COVER | KOB |
| 4. | YT30V00039S071 | [1] | CAP | KOB |
| 5. | YT30V00039S070 | [1] | SPACER | KOB |
| 6. | YT30V00039S072 | [1] | SPACER | KOB |
| 7. | PY30V00001S028 | [1] | SPRING | KOB |
| 8. | YT30V00039S068 | [1] | GUIDE | KOB |
| 9. | YT30V00039S033 | [1] | CAP | KOB |
| 10. | YT30V00039S024 | [2] | O-RING | KOB |
| 11. | 2436U1309S29 | [1] | CAP | KOB |
| 12. | ZD12P00800 | [2] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOB |
| 13. | YT30V00039S035 | [1] | SPOOL | KOB |
| 14. | YT30V00039S089 | [1] | PLUG | KOB |
| 15. | YT30V00039S037 | [1] | SPRING | KOB |
| 16. | YT21V00005F1 | [1] | CHECK VALVE | KOB |
| 17. | ZD12P01800 | [4] | O-RING | KOB |
| 18. | ZD12P01100 | [3] | O-RING | KOB |
| 19. | ZD85P01100 | [3] | BACK-UP RING | KOB |
| 20. | YT30V00042S022 | [1] | CAP | KOB |
| 21. | YT30V00039S004 | [1] | COVER | KOB |
| 22. | YT22V00012S004 | [1] | PLUG | KOB |
| 23. | YT30V00039S045 | [1] | POPPET | KOB |
| 24. | YT30V00039S044 | [1] | SPRING | KOB |
| 25. | YT30V00048F1 | [1] | VALVE | KOBControl |
| 26. | 2436U1514S38 | [1] | O-RING | KOB |
| 27. | ZS23C08060 | [4] | SCREW,Hex Socket Head, M8 x 60mm | KOBCap |
| 28. | ZS28C06020 | [4] | SCREW,Hex Socket Head, M6 x 20mm | KOBCap |
| 29. | ZD12P01000 | [2] | O-RING | KOB |
| 30. | ZD12P02200 | [1] | O-RING | KOB |
| 31. | YT30V00039S023 | [1] | CAP | KOB |
| 32. | 2436U2716S20 | [1] | SPRING | KOB |
| 33. | YT30V00039S026 | [1] | CHECK CONTROL | KOBPoppet |
| 34. | YT22V00016F1 | [2] | VALVE, PRESSURE RELI | KOBEF |
| . . | YT30V00042R200 | [1] | SPOOL | KOBRepair Kit, Consists Of Item: 4(1), 5(1), 6(1), 7(1), 8(1) |
