纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-017[08]) - VALVE INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
184 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YT30V00039S068 | [8] | GUIDE | KOB |
| 2. | YT30V00039S069 | [4] | SPRING | KOB |
| 3. | YT30V00039S070 | [8] | SPACER | KOB |
| 4. | YT30V00039S071 | [8] | CAP | KOB |
| 5. | YT30V00039S072 | [8] | SPACER | KOB |
| 6. | NSS | [1] | NOT SERVICED SEPARATELY | CONSpool |
| 11. | PY30V00001S028 | [4] | SPRING | KOB |
| . . | YT30V00039R100 | [1] | SPOOL | KOBRepair Kit, Consists Of Item: 1(1), 2(1), 3(1), 4(1), 5(1), 6(1) |
| . . | YT30V00039R200 | [2] | SPOOL | KOBRepair Kit, Consists Of Item: 1(1), 3(1), 4(1), 5(1), 7(1), 11(1) |
| . . | YT30V00039R400 | [1] | SPOOL | KOBRepair Kit, Consists Of Item: 1(1), 2(1), 3(1), 4(1), 5(1), 8(1) |
| . . | YT30V00039R500 | [1] | SPOOL | KOBRepair Kit, Consists Of Item: 1(1), 2(1), 3(1), 4(1), 5(1), 9(1) |
| . . | YT30V00039R700 | [1] | SPOOL | KOBRepair Kit, Consists Of Item: 1(1), 3(1), 4(1), 5(1), 10(1), 11(1) |
| . . | YT30V00047R100 | [1] | SPOOL | KOBRepair Kit, Consists Of Item: 1(1), 2(1), 3(1), 4(1), 5(1), 12(1) |
| . . | YT30V00047R200 | [1] | SPOOL | KOBRepair Kit, Consists Of Item: 1(1), 3(1), 4(1), 5(1),11(1), 13(1) |
