纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-020[00]) - HYDRAULIC LINES, PUMP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
400 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT30H00007F1 | [1] | Pump | |
| 1. | YT30H01049P1 | [1] | HOSE ASSY. | KOB |
| 2. | YT30H01047P1 | [1] | PIPE | KOB |
| 3. | YT30H01001P1 | [1] | TUBE | KOB |
| 4. | YB03H01118P1 | [1] | HYD CONNECTOR | KOB |
| 5. | 2444Z3713 | [1] | HYD CONNECTOR | KOB |
| 6. | ZE72X04000 | [1] | PLUG | KOB |
| 7. | ZC16X06100 | [4] | CLIP | KOB |
| 8. | ZD11G05500 | [1] | O-RING,54.40mm ID x 60.60mm OD x 3.10mm | KOB |
| 9. | ZD12A01800 | [2] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOB |
| 10. | ZD12P02600 | [1] | O-RING | KOB |
| 11. | ZS28C10040 | [4] | CAP,Hex Socket Head, M10 x 40mm | KOBScrew |
| 12. | ZS28C12035 | [4] | CAPSCREW,Hex Socket Head, M12 x 35mm | KOBSCREW Cap |
| 13. | ZW26K10000 | [4] | LOCK WASHER | KOBLock |
| 14. | ZW26K12000 | [4] | LOCK WASHER | KOB |
| 15. | ZX20H12072 | [1] | HOSE ASSY. | KOB |
| 16. | ZH32X08000 | [1] | 90 ELBOW,Male, 30° Fl, PF 1/2" x PF 1/2", O-Ring | KOBElbow |
