纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-021[01]) - HYDRAULIC LINES, UPPER (NIBBLER & BREAKER) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
382 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LF03H00009F1 | [1] | Upp. | |
| 1. | LF03H00005F1 | [1] | PIPE | KOBHyd. Lines, Upp. |
| 2. | LF03H01024D3 | [1] | HOSE ASSY. | KOB |
| 3. | YT02H01232D5 | [1] | HOSE ASSY. | KOB |
| 4. | YT03H01025D6 | [2] | FLEXIBLE HOSE | KOB |
| 5. | YT03H01025D7 | [1] | FLEXIBLE HOSE | KOB |
| 6. | YT03H01025D8 | [1] | FLEXIBLE HOSE | KOB |
| 7. | YT03H01025D9 | [1] | FLEXIBLE HOSE | KOB |
| 8. | YT03H01025DA | [1] | FLEXIBLE HOSE | KOB |
| 9. | LF03H01038D1 | [1] | HOSE ASSY. | KOB |
| 10. | LF03H01040D1 | [1] | HOSE ASSY. | KOB |
| 11. | YT03H01026DH | [1] | FLEXIBLE HOSE | KOB |
| 12. | YT03H01003D9 | [1] | FLEXIBLE HOSE | KOB |
| 13. | LF03H01041D1 | [1] | HOSE ASSY. | KOB |
| 14. | LF03H01039D1 | [1] | HOSE ASSY. | KOB |
| 15. | YT03H01144D2 | [2] | FLEXIBLE HOSE | KOB |
| 16. | ZS18C10055 | [1] | SCREW,Hex, M10 x 55mm | KOBCap |
| 17. | ZS18C12065 | [1] | SCREW,Hex, M12 x 65mm | KOBCap |
| 18. | ZA28F18008 | [5] | HYD CONNECTOR | KOB |
| 19. | ZM73C10025 | [2] | BOLT,M10x25mm - Course Thread | KOBSems |
| 20. | YT03H01019P1 | [2] | BUSHING | KOB Superseded by part number: YN03H01075P1 |
| 21. | LF03H01026P1 | [1] | BUSHING | KOB |
| 22. | YW03H01183P1 | [1] | CLAMP | KOB |
| 23. | LF03H01027P1 | [1] | CLAMP | KOB |
| 24. | ZY26X06030 | [1] | SPACER | KOB |
| 25. | ZD12P01800 | [9] | O-RING | KOB |
| 26. | LF03H01033P1 | [1] | BRACKET, SUPPORTING | KOB |
| 27. | LF03H01013P1 | [1] | RUBBER | KOB |
| 28. | ZW16H10000 | [5] | WASHER | KOB |
| 29. | ZW16H12000 | [1] | WASHER | KOB |
| 30. | PY01P01043D8 | [4] | CABLE TIE,102mm L | KOB |
| 31. | YX03H01046P1 | [3] | CLIP | KOB |
