神钢零件查询(MD180LC) - EXCAVATOR ASN YG0647 (1/80-12/06) (11-012) - VALVE ASSY, BRAKE (PROPELLING) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
544 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U1139F2 | [1] | BRAKE VALVE | KOB(PROPELLING) CONSISTS OF THE FOLLOWING PARTS |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONBODY |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONSPOOL ASSY |
| 3. | 2436U1139S3 | [2] | SPRING SEAT | KOB |
| 4. | 2436U1139S4 | [2] | SPRING | KOB |
| 5. | ZD12G04000 | [2] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 6. | ZD12P00900 | [2] | O-RING | KOBID 08.80 ± 0.17 x OD 12mm |
| 7. | 2436U1139S7 | [2] | COVER | |
| 8. | 2436U1139S8 | [2] | HYDRAULIC VALVE | KOB |
| 9. | 2483U223S4 | [2] | SPRING | KOB |
| 10. | 2436U1139S10 | [2] | PLUG | KOB |
| 11. | ZD12P01100 | [4] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 12. | ZS23C12045 | [8] | SCREW,Hex Socket Head, M12 x 45mm | KOBM12x1.75x45mm Superseded by part number: ZS28C12045 |
| 13. | ZD12G03500 | [2] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm |
| 14. | ZD12P01200 | [2] | O-RING | KOBID 11.80 ± 0.19 x OD 16mm |
| 15. | 2483U260S21 | [2] | PLUG | KOB |
| 16. | ZS23C12095 | [8] | SCREW,Hex Socket Head, M12 x 95mm | KOBM12x1.75x95mm |
| 17. | ZW22K12000 | [8] | LOCK WASHER | KOBID 12.2 x OD 17.8 x Th 2.5mm |
