神钢零件查询(MD180LC) - EXCAVATOR ASN YG0647 (1/80-12/06) (11-013) - VALVE ASSY, CONTROL ( SWING) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
309 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U1167F1 | [1] | CONTROL VALVE | KOB(SWING) CONSISTS OF THE FOLLOWING PARTS |
| 101. | NSS | [1] | NOT SOLD SEPARAT | CONCASING |
| 153. | NSS | [2] | NOT SOLD SEPARAT | CONPLUG |
| 154. | NSS | [2] | NOT SOLD SEPARAT | CONPLUG |
| 155. | NSS | [1] | NOT SOLD SEPARAT | CONPLUG |
| 161. | ZD12G03500 | [2] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm |
| 162. | 2436U665S262 | [2] | O-RING | KOB Superseded by part number: 2436U1457S162 |
| 163. | ZD12P00700 | [2] | O-RING,1.6mm Thk x 6.8mm ID, 90 Duro | KOBO-Ring -- ID 06.80 ± 0.16 x OD 10mm |
| 164. | ZD12P01100 | [3] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 165. | ZD12P01200 | [1] | O-RING | KOBID 11.80 ± 0.19 x OD 16mm |
| 171. | 2436U1485S171 | [8] | CAPSCREW | |
| 201. | 2436U1745S201 | [1] | COVER | |
| 202. | NSS | [1] | NOT SOLD SEPARAT | CONCOVER, VALVE |
| 211. | NSS | [1] | NOT SOLD SEPARAT | CONBALL |
| 231. | NSS | [1] | NOT SOLD SEPARAT | CONSEAT |
| 251. | NSS | [1] | NOT SOLD SEPARAT | CONPLUG |
| 253. | 2436U1745S253 | [1] | PLUG | KOB |
| 261. | ZD12P01000 | [1] | O-RING | KOBID 09.80 ± 0.17 x OD 13mm |
| 271. | ZS23C06025 | [4] | SCREW,Hex Socket Head, M6 x 25mm | KOBM06x1.0x25mm |
| 272. | 2436U1167S272 | [4] | CAPSCREW | |
| 301. | NSS | [1] | NOT SOLD SEPARAT | CONSPOOL |
| 321. | NSS | [1] | NOT SOLD SEPARAT | CONSPRING |
| 331. | NSS | [2] | NOT SOLD SEPARAT | CONSEAT, SPRING |
| 332. | NSS | [1] | NOT SOLD SEPARAT | CONBOLT, SPACER |
| 511. | NSS | [4] | NOT SOLD SEPARAT | CONPOPPET 1 |
| 512. | NSS | [1] | NOT SOLD SEPARAT | CONPOPPET 2 |
| 521. | NSS | [2] | NOT SOLD SEPARAT | CONSPRING 1 |
| 522. | NSS | [1] | NOT SOLD SEPARAT | CONSPRING 2 |
| 523. | NSS | [2] | NOT SOLD SEPARAT | CONSPRING 3 |
| 551. | NSS | [5] | NOT SOLD SEPARAT | CONPLUG |
| 561. | ZD12P02200 | [5] | O-RING | KOBID 21.80 ± 0.24 x OD 26mm |
| 601. | 2436R686F1 | [2] | VALVE | KOBSEE FIGURE 11-005 |
| . . | 2436U1167R100 | [1] | REPAIR KIT | KOBCASING ASSY, CONSISTS OF REF 101, 153, 154, 155, 164, 165, 301, 321, 331, 332, 511, 512, 521, 522 & 551 |
| . . | 2436U1167R200 | [1] | REPAIR KIT COVER ASSY VALVE, CONSISTS OF REF 202, 211, 231, 251 & 261 | REPAIR KIT COVER ASSY VALVE, CONSISTS OF REF 202, 211, 231, 251 & 261 |
