纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-027[01]) - CONTROL LINES, MAIN (NIBBLER & BREAKER + DOZER) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
725 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LF06H00023F1 | [1] | Main (Nibbler & Breaker + Dozer) | |
| 1. | YT06H00123F1 | [1] | TUBE | KOBControl Lines, Main |
| 2. | 2420R349D125 | [1] | HOSE,1250.00 mm | KOB Superseded by part number: HX21E04125DX |
| 3. | 2444R963D38 | [2] | FLEXIBLE HOSE | KOB |
| 4. | YT42H01128P1 | [1] | ELBOW | KOB |
| 5. | ZH42X06000 | [1] | 45 ELBOW,Male, 30° Fl, PF 3/8" x PF 3/8", O-Ring | KOB |
| 6. | YT06H01019P1 | [1] | GUIDE | KOB |
| 7. | ZM73C12025 | [1] | BOLT,M12x25mm - Course Thread | KOBSems |
| 8. | PY01P01043D8 | [2] | CABLE TIE,102mm L | KOB |
| 9. | YT06H00041F1 | [1] | TUBE | KOBControl Lines, Main |
| 10. | ZE72X06000 | [1] | PLUG | KOB |
| 11. | YT06H00059F1 | [1] | TUBE | KOBControl Lines, Main |
| 14. | NSS | [1] | NOT SERVICED SEPARATELY | CONControl Lines, Main YT06H00108F1 |
| 16. | 2444Z3711 | [1] | HYD CONNECTOR | KOB |
| 17. | ZH22X04006 | [1] | HYD CONNECTOR | KOB |
