纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-025[02]) - HYDRAULIC LINES, RETURN New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
292 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | LF32H00005F1 | [1] | PIPE | KOBHyd. Lines, Return |
| 2. | 2436R576F5 | [1] | CHECK VALVE | KOB |
| 3. | YT32H01102D4 | [1] | FLEXIBLE HOSE | KOB |
| 4. | ZH42X06000 | [1] | 45 ELBOW,Male, 30° Fl, PF 3/8" x PF 3/8", O-Ring | KOB |
| 5. | ZH32X08000 | [1] | 90 ELBOW,Male, 30° Fl, PF 1/2" x PF 1/2", O-Ring | KOBElbow |
| 6. | HH35X16016G1 | [4] | 90 ELBOW | KOB |
| 7. | 2420T2948D16 | [1] | U-BOLT | KOB |
| 8. | ZM73C10020 | [1] | BOLT,M10x20mm - Course Thread | KOBSems |
| 9. | ZN18C08007 | [4] | NUT | KOB |
| 10. | ZW16H08000 | [2] | WASHER | KOB |
| 11. | ZC46X31014 | [1] | CLIP | KOB |
| 12. | PY01P01043D6 | [2] | CABLE TIE,4.80mm W x 383mm L | KOB |
| 13. | YJ42H01141P1 | [1] | BUSHING | KOB |
| 14. | 2420Z2185 | [1] | GROMMET | KOB |
| 15. | LF32H01005P1 | [1] | BRACKET, SUPPORTING | KOB |
| 16. | ZM73C08020 | [2] | BOLT,M8x20mm - Course Thread | KOBSems |
| 17. | HH45X16016G1 | [1] | ELBOW | KOB |
