神钢零件查询(MD180LC) - EXCAVATOR ASN YG0647 (1/80-12/06) (11-020) - CYLINDER ASSY ( ARM) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
828 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2438U921F1 | [1] | CYLINDER ASSY ARM, CONSISTS OF THE FOLLOWING PARTS | CYLINDER ASSY ARM, CONSISTS OF THE FOLLOWING PARTS |
| . . | 2438U921F2 | [1] | CYLINDER | KOBARM, CONSISTS OF THE FOLLOWING PARTS Superseded by part number: 2438U1159F1 |
| 1. | 2438U921S1 | [1] | BARREL | KOB |
| 2. | 2438U552S2 | [2] | BUSHING | KOB |
| 3. | 2445R138D7 | [4] | SEAL,80mm ID x 95mm OD x 4mm Thk | KOBDust -- ID 80 x OD 95 x Th 4mm |
| 4. | 2438U921S4 | [1] | PISTON ROD | KOB |
| 5. | 2438U921S5 | [1] | PISTON | KOB |
| 6. | 2438U706S6 | [1] | SEAL | KOB |
| 7. | 2438U706S5 | [1] | O-RING | KOB |
| 8. | 2438U921S8 | [4] | RING | KOB |
| 9. | 2438U921S9 | [1] | NUT | KOB |
| 10. | 2438U921S10 | [1] | PLUNGER | KOB |
| 11. | 2438U921S11 | [1] | STOP | KOB |
| 12. | 2438U921S12 | [1] | RING | KOB |
| 13. | 2438U921S13 | [1] | AIR CONDITIONER | KOB |
| 14. | 2438U921S14 | [1] | O-RING | KOB |
| 15. | ZD12P13500 | [1] | O-RING | KOB |
| 16. | 2438U921S33 | [1] | BACK-UP RING | KOB |
| 17. | 2438U921S17 | [1] | BUSHING | KOB |
| 18. | B38K0029E27 | [1] | SNAP RING | KOB |
| 19. | 2438U720S19 | [1] | SEAL | KOB |
| 20. | 2438U720S20 | [1] | 0-RING | |
| 21. | 2438U720S21 | [1] | ROD | KOB Superseded by part number: 2418U130D17 |
| 23. | ZS23C20075 | [8] | SCREW,Hex Socket Head, M20 x 75mm | KOBM20x2.5x75mm |
| 24. | 2438U921S24 | [1] | BRACKET | BRACKET |
| 25. | 2438U921S25 | [1] | BUCKET | KOB |
| 26. | ZS16C10035 | [2] | SCREW | KOBM10x1.50x35mm Superseded by part number: ZS18C10035 |
| 27. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 28. | 2438U921S28 | [1] | SPACER | KOB |
| 29. | 2438U921S29 | [1] | CHECK VALVE | KOB |
| 30. | ZE82T12000 | [1] | PLUG | KOB3/4" PT |
| 31. | 2438U921S31 | [1] | ORIFICE | KOB |
| 32. | 2438U921S32 | [1] | SPRING | KOB |
| 34. | 2438U921S34 | [1] | DUST CAP | KOB |
| . . | 2438U921R100 | [1] | REPAIR KIT | KOBCONSISTS OF REF 14-16, 19-21, 34 Superseded by part number: 2438U921R100P |
| . . | 2438U921R110 | [1] | REPAIR KIT | KOBCONSISTS OF REF 6-8 Superseded by part number: 2438U921R110P |
| . . | 2438U921R120 | [1] | REPAIR KIT CONSISTS OF REF 4, 10, 11 | REPAIR KIT CONSISTS OF REF 4, 10, 11 |
