纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-031[02]) - SWING BRACKET GROUP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
352 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | LF02B00019F1 | [1] | BRACKET, SUPPORTING | KOBGroup, Swing |
| 2. | LF02B01025P2 | [1] | COVER | KOB |
| 3. | LF02B01016P2 | [1] | RUBBER | KOB |
| 4. | LF02B01017P2 | [1] | RUBBER | KOB |
| 5. | YT03H01036P1 | [2] | CLAMP | KOB |
| 6. | YN03H01075P1 | [2] | BUSHING,21mm ID x 39mm OD x 50mm L | KOB |
| 7. | ZM73C10025 | [2] | BOLT,M10x25mm - Course Thread | KOBSems |
| 8. | ZS18C08040 | [2] | SCREW,Hex, M8 x 40mm | KOBCap |
| 9. | ZW16H08000 | [2] | WASHER | KOB |
| 10. | LF02B00020F1 | [1] | BRACKET, SUPPORTING | KOBGroup, Swing |
