纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-034[01]) - CONTROL LINES, REMOTE (NIBBLER & BREAKER + AUGER) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
785 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT68H00094F1 | [1] | Remote (Nibbler & Breaker + Auger) | |
| 1. | YN30V00080F1 | [1] | VALVE | KOBPilot |
| 2. | 2420R349D092 | [2] | HOSE | KOB Superseded by part number: 2420R349D095 |
| 3. | 2420R349D250 | [1] | HOSE,2500.00 mm | KOB |
| 4. | 2420R349D270 | [1] | HOSE | KOB |
| 5. | ZH32X04000 | [2] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOB90 |
| 6. | ZH42X04000 | [1] | 45 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOB45 |
| 7. | HH45X04004G5 | [1] | ELBOW | KOB |
| 8. | ZE72X04000 | [1] | PLUG | KOB |
| 9. | HM83C10030G1 | [2] | BOLT | KOBSems |
| 10. | YX52S00013P1 | [1] | SENSOR | SMPress Superseded by part number: LC52S00019P1 |
