| 1. |
88011
|
[11] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5
|
NH
|
| 2. |
87670
|
[4] |
BOLT,1/2" - 13 x 1-1/4", Full Thd, Gr 5
|
NH
|
| 3. |
87689
|
[4] |
BOLT,1/2"-13 x 1.813" OAL, Gr 5
|
NH
|
| 4. |
87974
|
[4] |
BOLT,Hex, 1/2" - 13 x 2 3/4", Gr 5
|
WIN
Hex, 1/2"-13 x 2 3/4", G5
|
| 5. |
86629544
|
[4] |
NUT,5/16” – 18, GR B
|
NH
Superseded by part number: 280736
|
| 6. |
9637692
|
[10] |
NUT,3/8"-16, GB
|
NH
|
| 7. |
9636698
|
[12] |
NUT,1/2"-13, GB
|
NH
Superseded by part number: 88871
|
| 9. |
80702
|
[14] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
|
| 10. |
80700
|
[8] |
WASHER,0.56" ID x 1.38" OD x 0.11" Thk
|
NH
|
| 11. |
88146
|
[4] |
BOLT,Hex, 1/4" - 20 x 1", Gr 5
|
PA
Superseded by part number: 86505867
|
| 12. |
20356
|
[4] |
NUT,1/4"-20, GB
|
PA
Superseded by part number: 280129
|
| 13. |
9635884
|
[4] |
BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5
|
NH
|
| 14. |
3419
|
[2] |
CAP
|
FLX
vinyl 1 5/8" x 1 1/2"
|
| 15. |
8763
|
[4] |
FOOT
|
FLX
rubber, 1 1/2" od x 1/4" id x 3/4" Superseded by part number: 51200147, 51200147, NLS
|
| 18. |
87613959
|
[1] |
TOP
|
SAS
platform 2 tank
|
| 19. |
GL-188
|
[2] |
LADDER
|
FLX
hitch frame
|
| 20. |
87614474
|
[1] |
HANDRAIL
|
SAS
2 tank
|
| 21. |
GL-192
|
[1] |
LADDER
|
FLX
upper
|
| 22. |
GL-193
|
[1] |
LADDER
|
FLX
lower tank
|
| 22. |
87420825
|
[1] |
LADDER
|
SAS
lower tank 430 bushel cart
|
| 23. |
GL-330
|
[1] |
PLATFORM
|
FLX
frame
|
| 24. |
GL-350
|
[2] |
GRATING
|
FLX
top platform - flip up
|
| 25. |
84496340
|
[1] |
BRACKET
|
SAS
Ladder Bracket Top RH
|
| 25. |
84496341
|
[1] |
BRACKET
|
SAS
Ladder Bracket Top LH
|
| 26. |
GL-356
|
[1] |
HANDRAIL
|
FLX
frame LH
|
| 27. |
GL-755
|
[1] |
RAIL ASSY.
|
FLX
right - frame mount
|
| 28. |
84333264
|
[2] |
LUG
|
SAS
Mounting, Top Platform
|
| 29. |
84333266
|
[2] |
BRACKET
|
SAS
Brace, Floor, Platform
|
