凯斯零件查询(2330) - PRECISION AIR CART (1/08-12/15) (39.100.03[02]) - PLATFORN ASSEMBLY (2 TANK) (07/2011 +) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
891 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84248627
|
[1] |
HANDRAIL
|
SAS
Assembly, 2 Tank, RH
|
| 2. |
84258491
|
[1] |
HANDRAIL
|
SAS
Assembly, 2 Tank, LH
|
| 3. |
84248761
|
[1] |
PLATFORM
|
SAS
Assembly, Base, 2 Tank, PNTD Black
|
| 4. |
84300010
|
[1] |
STRIP
|
SAS
Anti-Slip. 305mm Long
|
| 5. |
88043
|
[8] |
BOLT,Hex, 1/2" - 13 x 3 1/4", Gr 5
|
NH
1/2-13X3-1/4 GR5 ZND 0.5625 X 1.375 X 0.109 CST ZND Prev Torque, All Mtl 1/2-13 GR B ZN
|
| 6. |
80700
|
[16] |
WASHER,0.56" ID x 1.38" OD x 0.11" Thk
|
NH
0.5625 X 1.375 X 0.109 CST ZND
|
| 7. |
9636698
|
[8] |
NUT,1/2"-13, GB
|
NH
Prev Torque, All Mtl 1/2-13 GR B ZN Superseded by part number: 88871
|
| 8. |
419988A1
|
[4] |
BOLT
|
FLX
0.375 X 2 UNC GR2 HH YZD 0-ALL TH
|
| 9. |
425034A1
|
[4] |
RUBBER WASHER
|
FLX
Rubber Washer
|
| 10. |
9637692
|
[4] |
NUT,3/8"-16, GB
|
NH
Prev Torque, All Mtl 3/8-16 Gr B ZN
|
| 11. |
8772
|
[4] |
WASHER
|
SAS
Washer, Poly 0.375 I.D. Superseded by part number: 412911A1
|
