神钢零件查询(MD180LC) - EXCAVATOR ASN YG0647 (1/80-12/06) (12-001) - MOTOR ASSY ( PROPELLING) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
938 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2441U518F3 | [1] | HYDRAULIC MOTOR | KOBASSY PROPELLING, CONSISTS OF THE FOLLOWING PARTS Superseded by part number: 2441U518F4 |
| 1. | 2441U518S1 | [1] | SHAFT | SHAFT |
| 2. | 2441U518S2 | [1] | CASING | KOB |
| 3. | 2441U518S3 | [1] | SNAP RING | KOB |
| 4. | 2441U518S4 | [1] | ROLLER BEARING | KOB |
| 5. | 2441U518S5 | [2] | RING, SNAP | RING, SNAP |
| 6. | ZD11G08500 | [1] | O-RING,84.40mm ID x 90.60mm OD x 3.10mm | KOBID 84.40 ± 0.61 x OD 90mm |
| 7. | 2441U518S7 | [1] | OIL SEAL | KOB |
| 8. | 2441U518S8 | [1] | PLATE | KOB |
| 9. | 2441U518S9 | [1] | RETAINING PLATE | KOB |
| 10. | 2441U518S10 | [1] | RING | KOB |
| 11. | 2441U518S11 | [9] | PISTON | KOB |
| 12. | 2441U518S12 | [1] | CYLINDER-BLOCK | CYLINDER-BLOCK |
| 13. | 2441U518S13 | [1] | RING | KOB |
| 14. | 2441U518S14 | [1] | SPRING SEAT | KOB |
| 15. | 2441U518S15 | [1] | PLATE | KOB |
| 16. | 2441U518S16 | [1] | SPRING | KOB |
| 17. | 2441U518S17 | [1] | COVER | COVER |
| 18. | 2441U518S18 | [2] | PIN | KOB |
| 19. | ZD12G16000 | [1] | O-RING,159.30mm ID x 170.70mm OD x 5.70mm | KOB |
| 20. | 2441U518S20 | [1] | NEEDLE BEARING | KOB |
| 21. | 2441U518S21 | [1] | RACE | KOB |
| 22. | 2441U518S22 | [1] | COUPLING | KOB |
| 23. | 2441U518S23 | [1] | SNAP RING | KOB |
| 24. | 2441U518S24 | [1] | SPACER | KOB |
| 25. | 2441U518S25 | [7] | PLATE | KOB |
| 26. | 2441U518S26 | [8] | PLATE | KOB |
| 27. | 2441U518S27 | [1] | PISTON | KOB |
| 28. | 2441U518S28 | [1] | PISTON RING | KOB |
| 29. | 2441U518S29 | [1] | PISTON RING | KOB |
| 30. | 2441U518S30 | [10] | SPRING | KOB |
| 31. | 2441U518S31 | [1] | COVER | KOBCOVER |
| 32. | ZD12G11500 | [1] | O-RING,114.40mm ID x 120.60mm OD x 3.10mm | KOBID 114.40 ± 0.94 x OD 120mm |
| 33. | ZS23C10025 | [10] | SCREW,Hex Socket Head, M10 x 25mm | KOBM10x1.50x25mm Superseded by part number: ZS28C10025 |
| 34. | 2441U518S34 | [1] | PLUG | KOBPLUG |
| 35. | ZS23C12060 | [5] | SCREW,Hex Socket Head, M12 x 60mm | KOBM12x1.75x60mm |
| 36. | 2441U518S36 | [1] | ORIFICE | KOB |
| 37. | ZS23C12090 | [2] | CAPSCREW,Hex Socket Head, M12 x 90mm | KOBSCREW M12x1.75x90mm |
| 38. | 2441U518S38 | [1] | SPACER | KOB |
| 39. | 2483U260S21 | [2] | PLUG | KOB |
| 40. | ZD12P01100 | [2] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 41. | 2441U518S41 | [1] | HOLDER | KOB |
| 42. | 2436R679F1 | [2] | VALVE PRESSURE RELIE | KOBSEE FIGURE 11-001 |
| 43. | NSS | [1] | NOT SOLD SEPARAT | CONNAME- PLATE |
| 45. | 2441U518S45 | [1] | SPRING SEAT | KOB |
| 46. | NSS | [2] | NOT SOLD SEPARAT | CONSCREW |
| 47. | ZS23C12120 | [2] | SCREW,Hex Socket Head, M12 x 120mm | KOBM12x1.75x120mm |
| 50. | ZD12P01800 | [2] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 51. | 2483U171S34 | [2] | PLUG | KOBPLUG |
