神钢零件查询(MD180LC) - EXCAVATOR ASN YG0647 (1/80-12/06) (12-002) - MOTOR ASSY ( SWING) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
126 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2441U549F1 | [1] | HYDRAULIC MOTOR | KOBSWING, CONSISTS OF THE FOLLOWING PARTS |
| 101. | 2441U549S101 | [1] | SHAFT | SHAFT |
| 106. | 2415U164S510 | [1] | SPACER | SPACER |
| 111. | NSS | [1] | NOT SOLD SEPARAT | CONCYLINDER |
| 113. | NSS | [1] | NOT SOLD SEPARAT | CONBUSHING, BALL |
| 114. | 2441U474S157 | [4] | SPRING | KOB |
| 115. | 2441U474S158 | [1 SET] | SHIM | KOB |
| 121. | NSS | [9] | NOT SOLD SEPARAT | CONPISTON |
| 122. | NSS | [9] | NOT SOLD SEPARAT | CONSHOE |
| 123. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE |
| 124. | 2441U564S124 | [1] | PLATE | KOB |
| 131. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE, VALVE |
| 133. | 2441U474S315 | [1] | RING, GUIDE | RING, GUIDE |
| 301. | 2441U549S301 | [1] | CASING | |
| 303. | NSS | [1] | NOT SOLD SEPARAT | CONCOVER, VALVE |
| 304. | 2441U549S304 | [1] | COVER, FRONT | COVER, FRONT |
| 401. | 2441U415S420 | [3] | CAPSCREW | CAPSCREW |
| 402. | ZS23C10040 | [9] | SCREW,Hex Socket Head, M10 x 40mm | KOBM10x1.50x40mm |
| 431. | ZR16X05000 | [1] | RING | KOBRetaining -- ID 50 x OD 64 x Th 2.0mm |
| 437. | 2441U549S437 | [1] | RING, SNAP | RING, SNAP |
| 443. | 2441U549S443 | [1] | ROLLER BEARING | KOB |
| 444. | 2441U549S444 | [1] | BEARING, ROLLER | BEARING, ROLLER |
| 451. | NSS | [1] | NOT SOLD SEPARAT | CONPIN |
| 464. | 2441U549S464 | [2] | PLUG | KOB |
| 471. | ZD12G11000 | [1] | O-RING,109.40mm ID x 115.60mm OD x 3.10mm | KOBID 109.4 ± 0.91 x OD 115mm |
| 472. | 2441U168S19 | [1] | O-RING | KOB |
| 485. | ZD12P01400 | [2] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 491. | 2441U549S491 | [1] | OIL SEAL | KOB Superseded by part number: 24100U84S25 |
| 990. | 2441U549S990 | [2] | PLUG | KOBPLUG Superseded by part number: 2441U436S468 |
| 991. | ZD12P01800 | [2] | O-RING | KOBID 17.8mm x OD 20.2mm |
| . . | 2441U549S13 | [1] | CYLINDER | KOBCONSISTS OF REF 111, 121, 122, 131 |
| . . | 2441U549S18 | [1] | BUSHING ASSY PLATE, CONSISTS OF REF 113, 123 | BUSHING ASSY PLATE, CONSISTS OF REF 113, 123 |
| . . | 2441U549S20 | [1] | KIT | KOBCOVER, VALVE, CONSISTS OF REF 303, 451 |
