纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-035[01]) - CONTROL LINES, REMOTE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
458 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT68H00101F1 | [1] | Remote | |
| 1. | 2420R537D140 | [2] | HOSE ASSY.,9.60mm ID x 1400mm L | KOB |
| 2. | LS68H01016D4 | [2] | HOSE,6.3mm ID x 1400mm L | KOB |
| 3. | HX23L04250CR | [1] | FLEXIBLE HOSE | KOB |
| 4. | HX23L04240CB | [1] | FLEXIBLE HOSE | KOB |
| 5. | HX23L04230CG | [1] | FLEXIBLE HOSE | KOB |
| 6. | HX23L04230CH | [1] | FLEXIBLE HOSE | KOB |
| 7. | HX23L04300CH | [1] | FLEXIBLE HOSE | KOB |
| 8. | HX23L04290CR | [1] | FLEXIBLE HOSE | KOB |
| 9. | HX23L04290CB | [1] | FLEXIBLE HOSE | KOB |
| 10. | HX23L04290CG | [1] | FLEXIBLE HOSE | KOB |
| 11. | PY01P01043D8 | [3] | CABLE TIE,102mm L | KOB |
