纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-035[03]) - CONTROL LINES, REMOTE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
123 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN30V00111F1 | [2] | HYDRAULIC VALVE | SMPilot |
| 2. | YT30V00008S151 | [1] | PLATE | KOB |
| 3. | 2436U1277S211 | [4] | PLUG | KOB |
| 4. | 2436U2938S212 | [4] | ROD | KOBPush |
| 5. | 2436U1277S213 | [4] | SEAL | KOB |
| 6. | ZD12P02000 | [4] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOB |
| 7. | YT30V00008S216 | [2] | SEAT | KOB |
| 8. | YT30V00008S10 | [2] | SEAT | KOB Superseded by part number: YT30V00008S010 |
| 9. | 2436U1277S217 | [4] | WASHER | KOB |
| 10. | PX30V00043S221 | [4] | SPRING | KOB |
| 11. | YN30V00069S241 | [2] | SPRING | KOB |
| 12. | YN30V00069S242 | [2] | SPRING | KOB |
| 13. | 2436U2581S301 | [1] | FLEXIBLE JOINT | KOB |
| 14. | YT30V00008S302 | [1] | PLATE | KOB |
| 15. | YT30V00008S312 | [1] | NUT | KOB |
| 16. | YT30V00008S501 | [1] | BOOT | KOB |
