纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-037[00]) - CONTROL LINES, PUMP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
867 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT06H00065F1 | [1] | Pump | |
| 1. | YT06H00120F1 | [1] | TUBE | KOBPump |
| 2. | 2420R349D068 | [1] | HOSE | KOB |
| 3. | 2420R349D125 | [1] | HOSE,1250.00 mm | KOB Superseded by part number: HX21E04125DX |
| 4. | ZH32X06000 | [1] | 90 ELBOW,Male, 30° Fl, PF 3/8" x PF 3/8", O-Ring | KOB90 |
| 5. | ZH42X04000 | [2] | 45 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOB45 |
| 6. | ZE72X08000 | [1] | PLUG | KOB |
| 7. | ZM73C10020 | [1] | BOLT,M10x20mm - Course Thread | KOB |
| 8. | ZC45X46014 | [1] | CLIP | KOB Superseded by part number: ZC46X46014 |
| 9. | YX32H01011P1 | [1] | BUSHING,33mm ID x 49mm OD x 50mm L | KOB |
| 10. | PU13E01002D4 | [1] | TUBE | KOB |
| 11. | PY01P01043D3 | [1] | CABLE TIE,188mm L | KOB |
| 12. | 2444Z2894 | [2] | 90 ELBOW | KOB |
| 13. | 2444Z4101 | [1] | HYD CONNECTOR | KOB |
