纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-038[01]) - CONTROL LINES, PROPEL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
414 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LF62H00003F1 | [1] | Propel Rops Cab | |
| 1. | LF62H00004F1 | [1] | TUBE | KOBControl Lines, Propel |
| 2. | YN30V00070F2 | [1] | PILOT VALVE | KOB |
| 3. | 2420R349D082 | [2] | HYDRAULIC HOSE,6.35 mm ID x 820.00 mm | KOB Superseded by part number: 2420R349D085 |
| 4. | 2420R349D210 | [2] | FLEXIBLE HOSE | KOB |
| 5. | 2420R349D240 | [2] | HOSE,2400.00 mm | KOB Superseded by part number: HX21E04240DX |
| 6. | HH25X04004G2 | [1] | HYD CONNECTOR | KOB |
| 7. | ZH22X04000 | [1] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB |
| 8. | YF62H01001P1 | [3] | RUBBER BAND | KOB |
| 9. | ZM73C08025 | [4] | BOLT,M8x25mm - Course Thread | KOBSems |
| 10. | YX52S00013P1 | [2] | SENSOR | SMPress Superseded by part number: LC52S00019P1 |
| 11. | PY01P01043D3 | [1] | CABLE TIE,188mm L | KOB |
| 12. | PY01P01043D8 | [1] | CABLE TIE,102mm L | KOB |
| 13. | YN13E01375P1 | [1] | CLIP,M8 x 8.20mm Shank | KOB |
| 14. | YT62H00008F1 | [1] | TUBE | KOBControl Lines, Propel |
| 15. | 2444Z2525 | [2] | HYD CONNECTOR | KOB |
| 16. | ZH32X04000 | [4] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOB90 |
