| . . | 24100J9237F1 | [1] | REWORK, REMOTE-CONTROL | |
| 1. | 2444Z2457 | [1] | TEE | KOB |
| 2. | 2420R349D048 | [1] | HOSE ASSY. | KOB480mm Long (18-57/64 in) Superseded by part number: 2420R349D050 |
| 3. | ZH22X04000 | [4] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| 4. | 2436R688F2 | [2] | SOLENOID VALVE | KOB |
| 5. | ZS13C06055 | [2] | SCREW | HITM06x1.0x55mm Superseded by part number: ZS18C06055 |
| 6. | ZW22X06000 | [2] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 7. | ZH21M08004 | [1] | HYD CONNECTOR | KOBCONNECTOR |
| 8. | ZX15K08058 | [1] | TUBE, NYLOM, N2 | TUBE, NYLOM, N2 |
| 9. | 2444T2501D1 | [1] | TEE | KOB |
| 10. | 2444Z2336 | [1] | TEE | KOBTee -- 1/4"x3/8"x3/8"PF (Incls. O-Ring ZD12P01100) |
| 11. | 2444R963D4 | [1] | HOSE | KOB |
| 12. | 2420R349D090 | [1] | HOSE,6.35mm ID x 900mm L | KOB900mm Long (35-7/16 in) |
| 13. | 2436R395F2 | [2] | HYDRAULIC VALVE | KOB |
| 14. | ZS13C05050 | [4] | BOLT | BOLT |
| 15. | ZN13C06005 | [5] | NUT | KOBM06x1.0mm Superseded by part number: ZN18C06005 |
| 16. | 2420R349D200 | [1] | HOSE ASSY. | KOB2000mm Long (78-3/4 in) |
| 17. | 2420R349D120 | [1] | HOSE,6.35mm ID x 1200mm L | KOB |
| 18. | 2420R349D080 | [1] | HOSE,6.35mm ID x 800mm L | KOB800mm Long (31-1/2 in) |
| 19. | 2420R349D150 | [1] | HOSE,6.35mm ID x 1500mm L | KOBPF 1/4 |
| 20. | 2444Z2335 | [6] | CONNECTION | KOB |
| 21. | ZH52X04000 | [2] | TEE,30 Degree Fl, Male, PF 1/4" x 1/4" x 1/4", O-Ring | KOB1/4" PF (Incls. O-Ring 237-6004) |
| 22. | ZH42X04000 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 45° -- (Incls. O-Ring 237-6004) |
| 23. | ZH32X04000 | [9] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 24. | ZW26X05000 | [4] | LOCK WASHER | KOBLock -- ID 05 x OD 09 x Th 1.3mm |
| 25. | 2416P8779 | [1] | COVER | COVER |
| 26. | 2420R349D073 | [1] | HOSE ASSY | HOSE ASSY |
| 27. | 2420R349D100 | [3] | HOSE | KOB1000mm Long (39-3/8 in) Superseded by part number: HX21E04100DX |
| 28. | 2420R537D170 | [1] | HOSE,9.60mm ID x 1700mm L | KOB |
| 29. | 2420R537D183 | [1] | HOSE | HOSE |
| 30. | ZH22X06000 | [4] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400) |
| 31. | 2436R732F1 | [1] | SOLENOID VALVE | KOB |
| 32. | 2416P12084 | [1] | BRACKET | BRACKET |
| 33. | 2420R537D360 | [2] | HOSE,9.60mm ID x 3600mm L | KOB |
| 34. | ZX15K08005 | [2] | TUBE | KOB |
| 35. | ZS23C06035 | [4] | SCREW,Hex Socket Head, M6 x 35mm | KOBM06x1.0x35mm |
| 36. | ZW22K06000 | [4] | LOCK WASHER | KOBID 06 x OD 10 x Th 1.5mm |
| 37. | ZS13C10025 | [2] | CAPSCREW | KOBSCREW M10x1.50x25mm Superseded by part number: ZS18C10025 |
| 38. | ZN13C10008 | [2] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 39. | ZW22X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 40. | 24100N4776F1 | [1] | WIRING ASSY, SEE FIGURE 05-014 | |
| 41. | ZX56N04300 | [1] | HOSE | |
| 42. | ZX28N10075 | [1] | HOSE | HOSE |
| 43. | 2444Z2876 | [1] | CONNECTOR | CONNECTOR |
| 44. | ZF23H10004 | [1] | HYD CONNECTOR | KOB |
| 45. | ZH51K08000 | [2] | TEE | KOB |
| 46. | 2432Z290 | [15] | CLIP | KOBWire Ties -- 185mm Long Superseded by part number: PY01P01043D3 |
| 47. | 24100J6136F4 | [1] | REMOTE-CONTROL ASSY, SEE FIGURE 03-002 | |
| 48. | ZS13C08085 | [2] | CAPSCREW | CAPSCREW |
| 49. | ZW22X08000 | [2] | LOCK WASHER | KOBID 08 x OD 15.4 x Th 2.0mm Superseded by part number: 83990583 |
| 50. | ZN13C08007 | [2] | NUT | KOBM08x1.25mm Superseded by part number: ZN18C08007 |
| 51. | ZH52F04000 | [2] | TEE | HIT |
| 52. | 2420R349D015 | [1] | HOSE | KOB |
| 53. | 2420R349D050 | [2] | HOSE,500.00 mm | KOB500mm Long (19-11/16 in) |
| 54. | 2420R349D025 | [1] | HOSE | KOBFLEXIBLE HOSE Superseded by part number: HX21E04025DX, 77254021 |
| 55. | 2479R1337F1 | [1] | PRESSURE SWITCH | KOB |
| 56. | 2436R757F1 | [1] | VALVE, REDUCTION | VALVE, REDUCTION |
| 57. | ZX15K08045 | [1] | TUBE | KOB |
| 58. | 2444Z2525 | [1] | HYD CONNECTOR | KOB1/4"PFx35mm Long (Incls. O-Ring ZD12P01100) Superseded by part number: 72217408 |
| 59. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 60. | ZH31M08004 | [2] | ELBOW | KOB |
| 61. | 2444T3324 | [1] | TEE | KOB |
| 62. | ZF23G10004 | [1] | HYD CONNECTOR | KOB |
| 63. | 2444Z2538 | [1] | HYD CONNECTOR | KOBTEE |
| 64. | ZX56N04060 | [1] | HOSE | HOSE |
| 65. | 2420R349D050 | [1] | HOSE,500.00 mm | KOB500mm Long (19-11/16 in) |
| 66. | ZX15K08200 | [1] | TUBE | KOB |
| 67. | 2432N1134 | [1] | LABEL | LABEL |
