纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-039[02]) - CONTROL LINES, MULTI New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
918 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2420R349D034 | [1] | HOSE | KOB Superseded by part number: 2420R349D035 |
| 2. | 2420R349D046 | [1] | FLEXIBLE HOSE | KOB Superseded by part number: 2420R349D050 |
| 3. | 2420R349D052 | [1] | FLEXIBLE HOSE | SM Superseded by part number: 2420R349D055 |
| 4. | 2420R349D060 | [1] | HOSE,6.35mm ID x 700mm L | KOB |
| 5. | 2420R349D072 | [1] | FLEXIBLE HOSE | SMAssy. Superseded by part number: 24820R63D072 |
| 6. | 2420R349D082 | [1] | HYDRAULIC HOSE,6.35 mm ID x 820.00 mm | KOB Superseded by part number: 2420R349D085 |
| 7. | 2420R349D090 | [1] | HOSE,6.35mm ID x 900mm L | KOB |
| 8. | 2444T2524 | [1] | HYD CONNECTOR | KOB |
| 9. | 2444Z2525 | [2] | HYD CONNECTOR | KOB |
| 10. | ZH22X04000 | [1] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB |
| 11. | 2444Z2894 | [5] | 90 ELBOW | KOB |
| 12. | ZH32X04000 | [3] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOB90 |
| 13. | ZH42X04000 | [10] | 45 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOB45 |
| 14. | YX52S00013P1 | [6] | SENSOR | SMPress Superseded by part number: LC52S00019P1 |
| 15. | ZE72X04000 | [4] | PLUG | KOB |
| 16. | ZM73C08035 | [4] | BOLT,M8x35mm - Course Thread | KOBSems |
| 17. | YT64H01168P1 | [2] | TEE | KOB |
| 18. | 2444T2528 | [2] | HYD CONNECTOR | KOB |
| 19. | 2420R349D094 | [1] | HOSE | KOB |
