凯斯零件查询(2330) - PRECISION AIR CART (1/08-12/15) (39.110.10) - TOW BETWEEN SMV MOUNT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
983 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
7770
|
[2] |
NUT,Hex, 1/4 - 20, Cl 5
|
NH
|
| 2. |
88206
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
NH
|
| 3. |
88902
|
[2] |
NUT,3/8"-16
|
NH
|
| 4. |
80701
|
[2] |
WASHER,0.31" ID x 0.73" OD x 0.07" Thk
|
NH
|
| 5. |
80702
|
[2] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
|
| 6. |
412742A1
|
[1] |
WARNING SIGN
|
FLX
smv steel back 4 holes
|
| 7. |
9707580
|
[2] |
BOLT,Hex, 1/4" - 20 x 3/4", Gr 5, Full Thd
|
NH
|
| 8. |
80682
|
[2] |
LOCK WASHER,1/4"
|
PA
|
| 9. |
GL-156FR
|
[1] |
SUPPORT
|
FLX
tank end top
|
| 10. |
GM-612
|
[1] |
BRACKET
|
FLX
smv sign
|
| 11. |
GM-623
|
[1] |
TANK
|
FLX
154 bushel male
|
