凯斯零件查询(2330) - PRECISION AIR CART (1/08-12/15) (39.110.11) - HITCH STEERING TELESCOPIC Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
745 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84279774
|
[1] |
HITCH
|
SAS
Assy
|
| 2. |
84271950
|
[1] |
PIPE
|
SAS
Lower, 5 and 6 Not included
|
| 3. |
84290600
|
[2] |
BUSHING
|
SAS
|
| 4. |
438-11616
|
[4] |
LOCK PIN,1/4" x 1", Slotted
|
CAS
Superseded by part number: 84158591
|
| 5. |
1728
|
[1] |
BOLT
|
SAS
Superseded by part number: 9602223
|
| 6. |
231-41416
|
[2] |
NUT,1"-8, GB
|
CON
Superseded by part number: 280286
|
| 7. |
1757
|
[2] |
WASHER
|
FLX
Superseded by part number: 87325446
|
| 8. |
84271955
|
[1] |
UNIVERSAL JOINT
|
SAS
|
| 9. |
3632
|
[1] |
BOLT
|
FLX
1 x 8 UNC GR5 YZD Superseded by part number: 18682
|
| 10. |
2132
|
[1] |
LOCK NUT,5/8"-11, GB
|
FLX
Superseded by part number: 85700693
|
| 11. |
84277914
|
[1] |
COLLAR
|
SAS
|
| 12. |
2482
|
[1] |
BOLT,Hex, 5/8"-11 x 3", G5
|
FLX
Superseded by part number: 87338
|
| 13. |
84280917
|
[1] |
HITCH
|
SAS
Superseded by part number: 47399183
|
| 14. |
84271930
|
[1] |
PIPE
|
SAS
Upper
|
| 16. |
3951
|
[2] |
U-BOLT
|
CAS
|
| 17. |
84271967
|
[1] |
PLATE
|
SAS
|
