神钢零件查询(MD180LC) - EXCAVATOR ASN YG0647 (1/80-12/06) (05-005) - RADIATOR ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
162 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2452U374F2 | [1] | RADIATOR ASSY | RADIATOR ASSY |
| 1. | 2452U374S1 | [1] | CORE, RADIATOR | KOB |
| 2. | 2452U221S111 | [1] | CAP | KOBPRESS Superseded by part number: 2414Z262 |
| 3. | 2452U374S3 | [1] | PIPE | |
| 4. | 2452U267S8 | [2] | CLIP | KOB |
| 5. | 2452U221S18 | [1] | DRAINCOCK/TAP SUPPLY | KOB |
| 6. | 2452U221S19 | [1] | PIPING, DRAIN | |
| 7. | 2452U374S7 | [1] | SHROUD | KOB |
| 8. | 2452U374S8 | [8] | BOLT ASSY | BOLT ASSY |
| 10. | 2452U374S10 | [8] | BOLT | KOB |
| 11. | 2452U374S11 | [4] | BOLT ASSY | |
| 12. | 2452U374S12 | [1] | SUPPORT | |
| 13. | 2452U374S13 | [2] | PACKING | PACKING |
| 14. | 2452U374S14 | [1] | PACKING | PACKING |
| 16. | 2452U374S16 | [1] | COOLER ASSY. | KOB |
