神钢零件查询(MD180LC) - EXCAVATOR ASN YG0647 (1/80-12/06) (05-004) - CLEANER ASSY, AIR Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
365 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2446U189F2 | [1] | AIR CLEANER | KOBCLEANER ASSY, AIR, SEE FIGURE 05-001 |
| 1. | 2446U154S1 | [1] | BODY | KOB |
| 2. | R51N0007S3 | [1] | ELEMENT | KOBELEMENT (OUTER) Superseded by part number: 2451U180-3A |
| 3. | 2446Z147S5 | [1] | NUT | KOBNUT ASSY |
| 4. | 2446U154S5 | [1] | BAFFLE | BAFFLE |
| 6. | 2446U154S7 | [1] | CLAMP | KOB |
| 7. | 2446U154S8 | [1] | O-RING | O-RING |
| 8. | R51N0007S9 | [1] | NIPPLE | NIPPLE |
| 9. | 2446U189S1 | [1] | CUP | KOBCUP ASSY |
| 10. | 2446U189S2 | [1] | VALVE VACUITER | VALVE VACUITER |
