纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-051[03]) - CONTROLS, OPERATORS (DOZER) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
422 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YT03M01290F1 | [1] | HANDLE GRIP | KOBAssy. |
| 2. | YT03M01292F1 | [1] | HANDLE GRIP | KOBAssy., Serial Range: LF06-04501-LF06-04544 Superseded by part number: YN03M02123F2 |
| 3. | PW03M01960F1 | [1] | HANDLE | KOB(With 1 Switch) |
| 4. | YN03M02124P1 | [1] | LEVER | SM |
| 5. | ZP26D05028 | [1] | PIN,5mm OD x 28mm L, Slotted | KOBSpring |
| 2. | YN03M02123F2 | [1] | HANDLE GRIP | KOBAssy., Start Serial: LF06-04545 |
| 6. | YT03M01291F1 | [1] | HANDLE GRIP | KOBAssy. |
| 7. | PW03M01962F1 | [1] | HANDLE | KOB(With 2 Switches & Prop Switch) |
| 10. | ZN18C14011 | [2] | NUT | KOB |
| 11. | YN03M02114P1 | [2] | BELLOWS | SMBoot |
