纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-051[05]) - CONTROLS, OPERATORS (DOZER) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
500 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YT12P01071F1 | [1] | CLAMP | KOBAssy. |
| 2. | YT12P01068F1 | [1] | CLAMP | KOB |
| 3. | YT12P01069P1 | [1] | CLAMP | KOB |
| 4. | YT12P01065P1 | [1] | RUBBER PAD | KOB |
| 5. | YT12P01063F1 | [1] | CLAMP | KOB |
| 6. | YT12P01064P1 | [1] | PLATE | KOB |
| 8. | YT12P01044F1 | [1] | CLAMP | KOB |
| 9. | YT12P01045P1 | [1] | PLATE | KOB |
| 10. | YT12P01046P1 | [1] | RUBBER PAD | KOB |
| 11. | YT12P01047F1 | [1] | CLAMP | KOB |
| 12. | YT12P01048P1 | [1] | PLATE | KOB |
| 13. | YT12P01050P1 | [1] | RUBBER PAD | KOB |
| 14. | YY12P01053F1 | [1] | CLAMP | KOB |
| 15. | YY12P01054P1 | [1] | PLATE | KOB |
| 16. | YY12P01051P1 | [1] | RUBBER PAD | KOB |
| 17. | ZW26K06000 | [5] | LOCK WASHER | KOB |
| 18. | ZS28C06020 | [5] | SCREW,Hex Socket Head, M6 x 20mm | KOBCap |
