纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-051[08]) - CONTROLS, OPERATORS (DOZER) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
368 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | LF55M00002F1 | [1] | | |
| 2. | LF26M00001P1 | [1] | FLOOR MAT | KOB |
| 3. | YY26M00021P1 | [1] | FLOOR MAT | KOB |
| 4. | YY55M01030P1 | [1] | PEDAL | KOB |
| 5. | YT55M01065P3 | [1] | PEDAL | KOB |
| 6. | YY55M01022P2 | [1] | RUBBER SEAL | KOB |
| 7. | YN03M01858P1 | [1] | RUBBER PEDAL PAD | SM |
| 8. | YY55M01034P1 | [1] | LOCK | KOBAssy. |
| 9. | YT55M01075F1 | [1] | LOCK | KOBAssy. |
| 10. | YT55M01076P1 | [1] | | |
| 11. | 2405R312D1210 | [2] | BUSHING | KOB |
| 12. | YT55M01052P1 | [1] | BAR | KOB |
| 13. | YT55M01053P1 | [1] | BAR | KOB |
| 14. | ZP26K02512 | [1] | PIN | KOBSpring |
| 15. | YY55M01027P1 | [1] | PIN | KOBStopper |
| 16. | YT55M01067P1 | [1] | PLATE | KOB |
| 17. | ZM73C08020 | [8] | BOLT,M8x20mm - Course Thread | KOBSems |
| 18. | ZM73C10020 | [2] | BOLT,M10x20mm - Course Thread | KOBSems |
| 19. | ZM73C10016 | [2] | BOLT,M10x16mm - Course Thread | KOBSems |
