纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-054[01]) - CONTROLLER INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
933 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT22E00091F1 | [1] | | |
| 1. | YT22E00090F1 | [1] | ECU | KOBInstal |
| 2. | YT22E01190P1 | [1] | BRACKET, SUPPORTING | KOB |
| 3. | YT22E01195P1 | [1] | BRACKET | KOB |
| 4. | YN50S00047P1 | [1] | TOGGLE SWITCH | KOB |
| 5. | YN22M01014P1 | [1] | LABEL | KOB |
| 6. | ZM61C06016 | [6] | BOLT | KOBSems |
| 7. | ZM61C06025 | [7] | BOLT | KOBSems |
| 8. | ZM73C08020 | [4] | BOLT,M8x20mm - Course Thread | KOBSems |
| 9. | PM22C01020DH | [1] | INSULATING PANEL | KOBTrim |
| 10. | YT22E00063F4 | [1] | ECU | KOB Superseded by part number: YT22E00063F5 |
