纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-058[00]) - PLATE INSTALLATION, FLOOR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
241 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LF03M00032F1 | [1] | Floor | |
| 1. | LF03M00034P1 | [1] | CAB FLOOR | KOBFloor |
| 2. | YT03M00168F1 | [1] | PLATE | KOBInstal, Floor |
| 3. | YN03M02125P1 | [2] | INSULATOR BLOCK | SMMount, Rubber |
| 4. | ZM22C10035 | [8] | BOLT | KOBSems |
| 5. | ZW16H16000 | [10] | WASHER | KOB |
| 6. | ZN18C16013 | [2] | NUT | KOB |
| 7. | YT03M01293P1 | [2] | RUBBER MOUNTING | KOB |
| 8. | ZM73C10035 | [4] | BOLT,M10x35mm - Course Thread | KOBSems |
| 9. | ZS18C16050 | [8] | SCREW,Hex, M16 x 50mm | KOBCap, Serial Range: LF06-04541-LF06-04543 |
| 9. | ZS18C16055 | [8] | SCREW,Hex, M16 x 55mm | KOBCap, Start Serial: LF06-04544 |
| 10. | ZW16H20000 | [2] | WASHER | KOB |
| 11. | YY03M01309P1 | [2] | NUT | KOB |
| 12. | YY03M01172P1 | [2] | PLATE | KOB |
| 13. | YT03M01296P1 | [2] | , Start Serial: LF06-04544 | |
