神钢零件查询(MD180LC) - EXCAVATOR ASN YG0647 (1/80-12/06) (06-006) - REDUCTION UNIT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
557 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100X1996F2 | [1] | HYDRAULIC MOTOR | KOB |
| 1. | 2441U518F3 | [1] | HYDRAULIC MOTOR | KOB Superseded by part number: 2441U518F4 |
| 2. | R45P0018D30 | [1] | FLOAT | KOB Superseded by part number: ZD58F23940 |
| 3. | 2418J340 | [1] | HUB | HUB |
| 5. | 24100T185F1 | [1] | SHIM | KOB |
| 5-1. | 2420T4042D1 | [1] | SHIM | KOB |
| 5-2. | 2420T4042D2 | [1] | SHIM | KOB |
| 5-3. | 2420T4042D3 | [1] | SHIM | KOB |
| 5-4. | 2420T4042D4 | [1] | SHIM | KOB |
| 5-5. | 2420T4042D5 | [1] | SHIM | KOB |
| 5-6. | 2420T4042D6 | [1] | SHIM | KOB |
| 5-7. | 2420T4042D7 | [1] | SHIM | KOB |
| 5-8. | 2420T4042D8 | [1] | SHIM | KOB |
| 5-9. | 2420T4042D9 | [1] | SHIM | KOB |
| 5-10. | 2420T4042D10 | [1] | SHIM | KOB |
| 5-11. | 2420T4042D11 | [1] | SHIM | KOB |
| 6. | 2425R209 | [2] | BALL BEARING | KOB |
| 7. | 2418P11826 | [1] | RETAINER | RETAINER |
| 8. | ZS23C10030 | [18] | SCREW,Hex Socket Head, M10 x 30mm | KOBM10x1.50x30mm Superseded by part number: ZS28C10030 |
| 9. | 2401N588 | [1] | RING GEAR | KOB |
| 10. | ZS23C16080 | [15] | CAPSCREW,Hex Socket Head, M16 x 80mm | KOBSCREW M16x2.0x80mm |
| 11. | 2413J473 | [1] | AIR COMPRESSOR | AIR COMPRESSOR |
| 12. | ZS23C08016 | [6] | SCREW,Hex Socket Head, M8 x 16mm | KOBM08x1.25x16mm |
| 13. | 2418T13572 | [3] | LOCKING PLATE | KOB |
| 14. | 2418T13573 | [3] | THRUST WASHER | KOB |
| 15. | 2401P890 | [3] | PINION | KOB |
| 16. | 2401P887 | [1] | SUN GEAR | KOB |
| 17. | 2401P886 | [1] | GEAR | KOB |
| 18. | 2401P889 | [3] | PINION | KOB |
| 19. | 2401P885 | [1] | SUN GEAR | KOB |
| 20. | 2401P888 | [3] | PINION | KOB |
| 21. | 2418T7512 | [6] | THRUST WASHER | KOB |
| 22. | 2410P966 | [3] | SHAFT | KOB |
| 23. | 2413N558F1 | [1] | SPIDER | KOB |
| 24. | 2418T5414 | [6] | THRUST WASHER | KOB |
| 25. | ZR16X05000 | [3] | RING | KOBRetaining -- ID 50 x OD 64 x Th 2.0mm |
| 26. | 2413N557F1 | [1] | SPIDER | KOB |
| 27. | 2418T4564 | [6] | WASHER | KOBTHRUST |
| 28. | ZR16X04000 | [3] | RING | KOBRetaining -- ID 37 x OD 40 x Th 1.8mm |
| 29. | ZR16X04500 | [1] | RING | KOBRetaining -- ID 45 x OD 58 x Th 1.8mm |
| 30. | 2414N2632 | [1] | COVER | COVER |
| 31. | ZS23C10035 | [14] | SCREW,Hex Socket Head, M10 x 35mm | KOBM10x1.50x35mm |
| 32. | ZE82T12000 | [2] | PLUG | KOB3/4" PT |
