纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-062[08]) - CAB INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
686 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | LQ50C00001F1 | [1] | FRAME | SMWindow Assy. |
| 2. | LQ50C00002F1 | [1] | FRAME | SMWindow Assy. |
| 3. | LQ50C00001S003 | [1] | BRACKET | KOBAssy. |
| 4. | LQ50C00001S004 | [1] | BRACKET | KOBAssy. |
| 5. | LQ50C00001S005 | [1] | STRIKER | KOBSTRIKER |
| 6. | LQ02C01316F1 | [1] | STRIKER | KOBSTRIKER Superseded by part number: LQ02C01316S003, LQ02C01316S004, LQ02C01316S002, LQ02C01316S001 |
| 7. | LQ02C01316S001 | [1] | BRACKET | KOB |
| 8. | LQ02C01316S002 | [1] | HOOK | KOB |
| 9. | LQ02C01316S003 | [1] | STOP | KOB |
| 10. | LQ02C01316S004 | [2] | NUT | KOB |
| 11. | LQ50C00001S007 | [1] | CABLE TERMINAL | KOBAssy. |
| 12. | LQ50C00001S008 | [1] | SEAL, GLASS | KOBSEAL,WINDOW |
| 13. | LQ50C00001S009 | [1] | RUBBER BLOCK | KOBStopper |
| 14. | LQ50C00001S010 | [1] | STOP PLUG | KOB |
| 15. | LQ50C00001S011 | [2] | RUBBER BLOCK | KOBStopper |
| 16. | LQ50C00001S012 | [1] | SWITCH | KOB |
| 17. | LQ50C00001S013 | [7] | BOLT | KOB |
| 18. | LQ50C00001S014 | [2] | BOLT | KOB |
| 19. | LQ02C00031S031 | [6] | BOLT | KOB |
| 20. | LQ50C00001S016 | [2] | SCREW | KOB |
| 21. | LQ50C00001S017 | [1] | NUT | KOB |
| 22. | LQ50C00001S018 | [1] | INLET MANIFOLD | KOBHolder |
| 23. | LQ50C00001S019 | [1] | INLET MANIFOLD | KOBBracket |
| 24. | LQ50C00001S020 | [2] | BOLT | KOB |
| 25. | LQ50C00001S021 | [1] | SHIM | KOB |
