纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-062[09]) - CAB INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
787 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | LQ50C00002S001 | [1] | WINDOW FRAME | KOB Superseded by part number: LQ50C00003S001 |
| 2. | LQ50C00002S002 | [1] | GLASS | KOB |
| 3. | LQ50C00002S003 | [1] | BRACKET | KOB |
| 4. | LQ50C00002S004 | [1] | BRACKET | KOB |
| 5. | LQ50C00002S005 | [1] | BRACKET | KOB |
| 6. | LQ50C00002S006 | [1] | BRACKET | KOB |
| 7. | LQ50C00002S007 | [1] | ROLLER | KOB |
| 8. | LQ50C00002S008 | [3] | ROLLER | KOB |
| 9. | LQ50C00002S009 | [1] | COVER | KOB |
| 10. | LQ50C00002S010 | [1] | LOCK | KOB |
| 11. | LQ50C00002S011 | [2] | HANDLE | KOB |
| 12. | LQ50C00002S013 | [1] | RUBBER SEAL | KOB |
| 13. | LQ50C00002S014 | [2] | RUBBER BLOCK | KOB |
| 14. | LQ50C00002S015 | [1] | SPACER | KOB |
| 15. | LQ50C00002S016 | [2] | SCREW | KOB |
| 16. | LQ50C00001S013 | [19] | BOLT | KOB |
| 17. | LQ50C00002S018 | [2] | SCREW | KOB |
