纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-062[10]) - CAB INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
729 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YT53C00015F1 | [1] | | |
| 2. | LQ53C00003S001 | [1] | WIPER MOTOR | KOB |
| 3. | LQ53C01001F1 | [1] | WIPER ARM | KOBAssy. |
| 4. | LQ53C01001S001 | [2] | SCREW | KOBSems |
| 5. | LQ53C01001S002 | [1] | GUIDE | KOB |
| 6. | LQ53C01001S003 | [1] | WIPER BLADE | KOB |
| 7. | LQ53C01001S004 | [1] | ARM | KOBAssy. |
| 8. | LQ53C00003S003 | [1] | NOZZLE | KOB |
| 9. | YT53C00015S004 | [1] | RIGID TUBE | KOB |
| 10. | LQ53C00003S005 | [1] | INLET MANIFOLD | KOBHolder |
| 11. | LQ53C00003S006 | [1] | PACKING | KOB |
| 12. | LQ02C00031S032 | [2] | BOLT | KOB |
| 13. | LQ02C00031S030 | [1] | SCREW | KOB |
| 14. | LQ53C00003S009 | [4] | NUT | KOB |
| 15. | LQ53C00003S012 | [1] | HYD CONNECTOR | KOB |
| 16. | LQ14E00014S005 | [1] | COLLAR | SMClip |
| 17. | LQ80E00018F1 | [1] | | |
| 18. | LQ80E00018S001 | [2] | GROMMET | KOB |
