神钢零件查询(MD180LC) - EXCAVATOR ASN YG0647 (1/80-12/06) (06-008) - BEARING ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
524 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N3631F1 | [1] | BEARING ASSY SEE FIGURE 06-007 | BEARING ASSY SEE FIGURE 06-007 |
| 1. | 2425N311F1 | [1] | RACE, OUTER | |
| 1-1. | 2425N311 | [1] | RACE, OUTER | |
| 1-2. | 2420T4183 | [1] | PLUG | |
| 1-3. | 2419T1964D4 | [1] | PIN, TAPER | |
| 2. | 2401N591 | [1] | RACE, INNER | |
| 3. | 2425T307 | [115] | BALL | KOB |
| 4. | 2425T308 | [115] | RETAINER | KOB |
| 5. | 2445P114D2 | [1] | SEAL | KOB Superseded by part number: YN40F01024D4 |
| 6. | 2445P114D1 | [1] | SEAL | KOB Superseded by part number: YN40F01024D4 |
| 7. | 2432T1265 | [1] | LABEL | KOB Superseded by part number: YN22T00191P1 |
| 8. | 4020Z64 | [2] | RIVET | KOBOD 5.0 x 6.0mm Long Superseded by part number: 2420P623D7 |
| 9. | ZE82T04000 | [2] | PLUG | KOB1/4" PT |
| 10. | ZE82T02000 | [1] | PLUG | KOBPipe, 1.25" PT |
| . . | 2445P114D7 | [1] | SEAL KIT | KOBCONSISTS OF REF 5, 6 Superseded by part number: YN40F01024D4 |
