神钢零件查询(MD180LC) - EXCAVATOR ASN YG0647 (1/80-12/06) (06-009) - HYDR LINES, LOW Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
522 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J6070F2 | [1] | HYDR LINES, LOW | |
| 1. | 2418P11752 | [1] | TUBE | TUBE |
| 2. | 2418N2252D1 | [1] | TUBE | TUBE |
| 3. | 2418P11754 | [1] | TUBE | KOB |
| 4. | 2418N2253D1 | [1] | TUBE | TUBE |
| 5. | 2418P11753 | [1] | TUBE | KOB |
| 6. | 2418N2252D2 | [1] | RIGID TUBE | KOB |
| 7. | 2418P11755 | [1] | TUBE | TUBE |
| 8. | 2418N2253D2 | [1] | TUBE | KOB |
| 10. | 2418N2254D1 | [1] | TUBE | TUBE |
| 11. | 2418N2254D2 | [1] | TUBE | KOB |
| 12. | ZA23F28016 | [8] | CONNECTION | KOB1" PF - M36x1.50x49mm Long |
| 13. | ZD12P02900 | [8] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| 15. | ZA53B18000 | [1] | TEE | KOB |
| 16. | ZA23F18008 | [3] | HYD CONNECTOR | KOB1/2" PF - M26x1.50x41mm Long (No O-Ring supplied) |
| 17. | ZD12P01800 | [3] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 18. | ZA23B28000 | [4] | CONNECTION | KOBM36x1.50x43mm Long |
| 19. | 2432T2239 | [2] | CLAMP | KOB |
| 21. | ZW22X12000 | [4] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 22. | 2418T12363 | [1] | RIGID TUBE | KOB |
| 23. | ZS23C12055 | [4] | SCREW,Hex Socket Head, M12 x 55mm | KOBM12x1.75x55mm |
