凯斯零件查询(2330) - PRECISION AIR CART (1/08-12/15) (55.100.22) - ELECTRICAL - HARNESS, TRACTOR, 84261537 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
383 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84261537
|
[1] |
HARNESS
|
SAS
Power Extension
|
| 2. |
412732A1
|
[2] |
ELEC. TERMINAL PIN,3 - 6 mm2
|
FLX
terminal ring 10-12awg 5/16" yellow
|
| 3. |
87577735
|
[1] |
ELEC CONNECTOR
|
SAS
acc prl splce nonins
|
| 4. |
92277
|
[2] |
FUSE,30 Amp
|
NH
|
| 5. |
13972
|
[2] |
FUSE HOLDER
|
FLX
inline ato 12awg Superseded by part number: 84291729
|
| 6. |
425044A1
|
[2] |
TERMINAL CONNECTOR,22 - 18 SAE
|
FLX
terminal disc 22-18awg 1/4" f
|
| 7. |
225185C1
|
[1] |
TERMINAL CONNECTOR
|
CAS
disc 12-10awg
|
| 8. |
1983420C2
|
[1] |
RELAY
|
IH
12v 85 ohm c/w bracket
|
| 9. |
425054A1
|
[2] |
TERMINAL CONNECTOR,22 - 16 SAE
|
FLX
terminal ring 22-16awg 1/4 pvc Superseded by part number: 84244501
|
