神钢零件查询(MD180LC) - EXCAVATOR ASN YG0647 (1/80-12/06) (06-010) - INSTAL, CRAWLER TRACK Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
588 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J5143F1 | [1] | INSTAL, CRAWLER TRACK | |
| 1. | 24100J5141F2 | [2] | CHAIN | KOB |
| 1-1. | 2424J164D1 | [52] | LINK | KOB |
| 1-2. | 2424J164D2 | [52] | LINK | KOB |
| 1-3. | 2405P467 | [51] | BUSHING | KOB |
| 1-4. | 2419P1632 | [51] | PIN | KOB |
| 1-5. | 2405P468 | [1] | BUSHING | KOB |
| 1-6. | 2419P1633 | [1] | PIN | KOB |
| 1-7. | 2418T12108 | [2] | COLLAR CLAMP | KOB |
| 2. | 2424N161 | [104] | TRACK SHOE | KOB Superseded by part number: 2424N181, 77254663 |
| 8. | 2420P1513 | [416] | SCREW | KOB |
| 11. | 2420T4443 | [416] | NUT | KOB |
| . . | 24100J5143F3 | [1] | INSTAL, CRAWLER TRACK, CONSISTS OF REF 1, 8 & 11 | |
| 4. | 2424N162D2 | [104] | SHOE | SHOE |
