纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-069[01]) - GUARD INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
266 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LF21C00012F2 | [1] | | |
| 1. | LF21C00013F1 | [1] | GUARD | KOBInstal |
| 2. | LF21C01079F1 | [1] | GUARD | KOBAssy. |
| 3. | LF21C01149P1 | [1] | GUARD | KOB |
| 4. | YR21C01414P1 | [1] | INSULATION | KOB |
| 5. | LF21C01080P1 | [1] | INSULATION | KOB |
| 6. | YR21C01415P1 | [1] | INSULATION | KOB |
| 7. | LF21C01084P1 | [1] | RUBBER SEAL | KOB |
| 8. | YT21C01651P1 | [1] | INSULATION | KOB |
| 9. | YT21C01164DN | [1] | WEATHERSTRIP | KOB |
| 10. | YT21C01164DM | [1] | WEATHERSTRIP | KOB |
| 11. | YR21C01168DE | [3] | WEATHERSTRIP | KOB |
| 12. | YR21C01423P1 | [1] | INSULATION | KOB |
| 13. | YT21C01693P1 | [1] | INSULATION | KOB |
| 14. | YR21C01424P1 | [1] | INSULATION | KOB |
| 15. | YN21C01136D6 | [1] | STRIP | KOBWeather |
| 16. | PY21C01007DH | [1] | WEATHERSTRIP | KOB |
| 17. | YR21C01437P1 | [1] | INSULATION | KOB |
| 18. | YR21C01168DJ | [1] | WEATHERSTRIP | KOB |
| 19. | YF21C01765P1 | [1] | SPRING | KOB |
| 20. | ZM73C08016 | [5] | BOLT,M8x16mm - Course Thread | KOBSems |
| 21. | ZM73C12025 | [14] | BOLT,M12x25mm - Course Thread | KOBSems |
| 22. | YR21C01425F1 | [1] | BRACKET | KOBAssy. |
| 23. | YR21C01426P1 | [1] | BRACKET | KOB |
| 24. | YR21C01168DC | [1] | WEATHERSTRIP | KOB |
