纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-069[02]) - GUARD INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
696 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YT21C01632F1 | [1] | GUARD | KOBAssy. |
| 2. | YT21C01951P1 | [1] | GUARD | KOB |
| 3. | YR21C01168DK | [1] | RUBBER SEAL | KOBStrip, Weather |
| 4. | YT21C01652P1 | [2] | BRACKET | KOB |
| 5. | YT21C02040F1 | [1] | PILLAR | KOB |
| 6. | YT21C02011P3 | [1] | PILLAR | KOB |
| 7. | YT21C01822P1 | [1] | RUBBER SEAL | KOB |
| 8. | YT21C01941P1 | [1] | BRACKET | KOB |
| 9. | ZM73C08016 | [5] | BOLT,M8x16mm - Course Thread | KOBSems |
| 10. | ZM73C12025 | [14] | BOLT,M12x25mm - Course Thread | KOBSems |
| 11. | ZM73C12030 | [2] | BOLT,M12x30mm - Course Thread | KOBSems |
| 12. | YT21C02042P3 | [1] | BRACKET, SUPPORTING | KOB |
| 13. | YT21C01812P1 | [1] | PLATE | KOB |
| 14. | ZS18C12030 | [2] | SCREW,Hex, M12 x 30mm | KOBCap |
| 15. | ZW26X12000 | [2] | WASHER | KOB |
| 16. | 2418T10357 | [2] | WASHER | KOB Superseded by part number: 2418T12345 |
