凯斯零件查询(2330) - PRECISION AIR CART (1/08-12/15) (55.404.04) - AUGER LIGHTING Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
790 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87564182
|
[1] |
LIGHT
|
SAS
auger 55w pilot
|
| 2. |
9703399
|
[1] |
BULB,H3, 12V, 55W
|
WIN
lamp assy, halogen h3-12v-55w Superseded by part number:
|
| 3. |
425258A1
|
[1] |
HARNESS
|
FLX
auger light
|
| 4. |
87692877
|
[3] |
MULTIPOLE CONNECTOR,Male, 2 Cavities
|
BN
plastic 2c receptacle
|
| 5. |
225120C1
|
[2] |
TERMINAL CONNECTOR,Tin, 0.8mm
|
IH
18-20awg
|
| 6. |
225124C1
|
[2] |
SEAL,2 - 2.9 mm2
|
IH
seal grn 2.8-2 omm Superseded by part number: 84286327
|
| 7. |
87692855
|
[2] |
CONTACT HOUSING,Male, 2 Cavities
|
BN
plastic 2c plug
|
| 8. |
225122C1
|
[4] |
TERMINAL CONNECTOR,Tin, 1.0 - 2.0mm
|
IH
socket 14-16awg
|
| 9. |
225125C1
|
[8] |
SEAL
|
IH
Connector Grey 3.49 - 2.81 mm Superseded by part number: 87680710
|
| 10. |
225119C1
|
[4] |
TERMINAL
|
IH
14-16awg Superseded by part number: 87692882
|
| 11. |
13972
|
[1] |
FUSE HOLDER
|
FLX
inline ato 12awg Superseded by part number: 84291729
|
| 12. |
84090658
|
[1] |
FUSE,Lt Blue, 15 Amp
|
ZED
15 Amp, Type A
|
| 13. |
425061A1
|
[1] |
SWITCH
|
FLX
on/off
|
| 14. |
425064A1
|
[1] |
CABLE
|
FLX
jumper 1 m x 2c Packard Superseded by part number: 84335759
|
