凯斯零件查询(2330) - PRECISION AIR CART (1/08-12/15) (55.404.05) - BEACON LIGHTING Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
581 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
412915A1
|
[1] |
BEACON
|
FLX
assembly rotating yellow 12v
|
| 2. |
87506451
|
[1] |
HARNESS
|
SAS
beacon light 8.0 m
|
| 3. |
87692877
|
[2] |
MULTIPOLE CONNECTOR,Male, 2 Cavities
|
BN
plastic 2c receptacle
|
| 4. |
225120C1
|
[2] |
TERMINAL CONNECTOR,Tin, 0.8mm
|
IH
18-20awg
|
| 5. |
441656A1
|
[2] |
ELEC CONNECTOR
|
CAS
seal ppl 2.15-1.6mm
|
| 6. |
87692855
|
[1] |
CONTACT HOUSING,Male, 2 Cavities
|
BN
plastic 2c plug
|
| 7. |
225122C1
|
[2] |
TERMINAL CONNECTOR,Tin, 1.0 - 2.0mm
|
IH
socket 14-16awg
|
| 8. |
225125C1
|
[4] |
SEAL
|
IH
Connector Grey 3.49 - 2.81 mm Superseded by part number: 87680710
|
| 9. |
225119C1
|
[2] |
TERMINAL
|
IH
14-16awg Superseded by part number: 87692882
|
| 10. |
87682687
|
[1] |
BULB
|
SAS
35 watt halogen
|
