纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-069[04]) - GUARD INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
923 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | LF21C00017F1 | [1] | | |
| 2. | YT21C02048F1 | [1] | TRIM PANEL | KOBAssy. |
| 3. | YT21C02049P1 | [1] | INSULATION | KOB |
| 4. | ZM73C12025 | [11] | BOLT,M12x25mm - Course Thread | KOBSems |
| 5. | LF21C01172F1 | [1] | TRIM PANEL | KOBAssy. |
| 6. | LF21C01173P1 | [1] | TRIM PANEL | KOB |
| 8. | LF21C01159P1 | [1] | COVER | KOB |
| 9. | YT21C01891P1 | [1] | INSULATION | KOB |
| 10. | PM21C01136D1 | [1] | WEATHERSEAL STRIP | KOB |
| 11. | YR21C01168D1 | [1] | WEATHERSTRIP | KOB |
| 12. | PM21C01152DC | [1] | WEATHERSTRIP | KOB |
| 13. | YT21C01159D7 | [1] | WEATHERSTRIP | KOB |
| 14. | LS21C01093D1 | [1] | TRIM | KOB |
| 15. | LF21C01133P1 | [1] | INSULATION | KOB |
| 16. | LS21C01093DV | [1] | GASKET | KOBTrim |
| 17. | YN21C03212P1 | [2] | STOP | KOB |
| 18. | ZS18C12040 | [1] | SCREW,Hex, M12 x 40mm | KOBCap |
| 19. | ZN18F10008 | [2] | NUT | KOB |
| 20. | YN21C01395P1 | [2] | WASHER | KOB |
| 21. | YN21C01396P1 | [2] | WASHER | KOB |
| 22. | ZM32C12030 | [2] | BOLT | KOBSems |
| 23. | 2418T10357 | [2] | WASHER | KOB Superseded by part number: 2418T12345 |
| 24. | YN21C01757D2 | [2] | SHIM | KOB(2.0) |
| 25. | ZS18C12045 | [1] | SCREW,Hex, M12 x 45mm | KOBCap |
