神钢零件查询(MD180LC) - EXCAVATOR ASN YG0647 (1/80-12/06) (08-007) - CONDITIONER ASSY, AIR Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
468 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100U345F1 | [1] | CONDITIONER ASSY, AIR | |
| 1. | 24100U345S1 | [1] | CONDITIONER, AIR | |
| 2. | 24100U345S2 | [1] | CONDENSER | KOB |
| 3. | 24100U345S3 | [1] | AIRCOND. COMPRESSOR | KOB |
| 4. | 2414Z273 | [1] | DUCT, AIR | |
| 5. | 2414Z274 | [1] | DUCT, AIR | |
| 6. | 2414Z275 | [1] | DUCT, AIR | |
| 8. | 24100U345S8 | [1] | HOLDER | |
| 9. | 24100U344F1 | [1] | MANIFOLD | KOB |
| 10. | 24100U345S10 | [1] | CABLE, CONTROL | |
| 11. | 24100U345S11 | [2] | CABLE, CONTROL | |
| 12. | 24100U345S12 | [1] | HARNESS ASSY | |
| 13. | 24100U345S13 | [1] | TUBE | KOB |
| 14. | 24100U345S14 | [2] | HOSE | |
| 15. | 24100U345S15 | [1] | GROMMET | |
| 16. | 24100U345S16 | [1] | RELAY | KOB |
| 18. | 24100U345S18 | [3] | DRUM | |
