纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-069[06]) - GUARD INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
643 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YT21C00037F1 | [1] | | |
| 2. | YT22C00017F1 | [1] | COVER ASSY | KOB |
| 3. | YT22C01239P1 | [1] | HOOD | KOB |
| 4. | YT22C01190F1 | [1] | COVER ASSY | KOB |
| 5. | YT22C01236P2 | [1] | HOOD | KOB |
| 6. | YT22C01191P2 | [1] | COVER | KOB |
| 7. | YT22C01178P1 | [1] | SPRING | KOB |
| 8. | YT22C01179P1 | [1] | SPRING | KOB |
| 9. | ZM73C12020 | [4] | BOLT,M12x20mm - Course Thread | KOBSems |
| 10. | ZM73C12025 | [10] | BOLT,M12x25mm - Course Thread | KOBSems |
| 11. | ZM73C08020 | [2] | BOLT,M8x20mm - Course Thread | KOBSems |
| 12. | YT22C01185P1 | [1] | PLATE | KOB |
