纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-069[07]) - GUARD INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
573 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YT22C00018F1 | [1] | COVER ASSY | KOB Superseded by part number: YT22C00019F1 |
| 2. | YT22C01244P1 | [1] | HOOD | KOB |
| 3. | YT22C01205P1 | [1] | INSULATION | KOB |
| 4. | YT22C01175P1 | [1] | INSULATION | KOB |
| 5. | YT22C01246P1 | [1] | INSULATION | KOB |
| 6. | YT22C01245P1 | [1] | INSULATION | KOB |
| 7. | YT22C01204P1 | [1] | INSULATION | KOB |
| 8. | YT21C01034P2 | [1] | CATCH | KOB |
| 9. | YT21C01090F3 | [1] | LOCK | KOB |
| 10. | YR22C01025P2 | [1] | LOCK | KOB |
| 11. | YT21C01801P1 | [1] | PLATE | KOB |
| 12. | 2427Z2106D3 | [1] | WEATHERSTRIP | KOB |
| 13. | ZM73C06016 | [2] | BOLT,M6x16mm - Course Thread | KOBSems |
| 14. | YT21C01907P1 | [1] | ROD | KOB |
| 15. | YT21C01053P1 | [1] | CLIP | KOB |
| 16. | YT22C01230P1 | [1] | RUBBER SEAL | KOB |
| 17. | ZS41C05020 | [3] | SCREW,M5 x 20mm | KOBMachine |
| 18. | YT22C01216P1 | [1] | INSULATION | KOB |
| 19. | PM02C01035DD | [1] | WEATHERSTRIP | KOB |
| 20. | 2427P1836D29 | [1] | WEATHERSTRIP | KOB |
| 22. | YT21C01795P1 | [1] | STAY | KOB |
| 23. | YT21C01796P1 | [1] | BRACKET | KOB |
| 24. | YT21C01952P1 | [1] | STRIKER | KOBSTRIKER Superseded by part number: LG21C01443F1 |
| 25. | ZW16P10000 | [1] | WASHER | KOB |
| 26. | 2419R9D3 | [1] | PIN | KOB |
| 27. | ZM73C12025 | [10] | BOLT,M12x25mm - Course Thread | KOBSems |
| 28. | YF21C01782D2 | [1] | SHIM | KOB(4.5) |
